| Quantity: | |
|---|---|
5J100T
Fast
5J100T
| Transmission Model | 5J100TC |
| Transmission Application | MT |
| Input Torque | 1000 Nm |
| Maximum Speed | 2600 RPM |
| Installation length | 709 mm |
| Input Power | 199 KW |
| Weight Iron/Al Alloy | 190 Kg |
| Fuel Quantity | 10.5 L |
| Head gear ratio | 6.62 |
| 2 gear ratio | 3.99 |
| 3 gear ratio | 2.47 |
| 4 gear ratio | 1.55 |
| 5 gear ratio | 1 |
| Reverse gear 1 transmission ratio | 6.48 |
| Manipulative form | Various forms of remote manipulation are possible |
| Applicable vehicle models | Suitable for buses, trucks and various special vehicles with an input torque of 900-1000Nm |
2. Long service life, 1/2 gear adopts double-cone synchronizer, 3/4 gear, 5th gear adopts single-cone synchronizer, and the friction pair of the synchronizer adopts high-performance friction material, which has a long service life.
3. High transmission efficiency, using the world’s most advanced manufacturing equipment to ensure the precision of gear manufacturing, high transmission efficiency, fuel saving and high efficiency.
4. The shifting is light, the short-stroke synchronizer is adopted, the operating mechanism is optimized, and the counterweight design assists in completing the shifting, and the shifting force of the third gear minus the second gear is significantly lower than that of competitive products.
5. The speed ratio steps are arranged reasonably and the fuel economy is good.
6. This series of transmissions is suitable for all kinds of road transport passenger cars, light transport vehicles, etc.
