Basic Info

• OE Part No.: 1315 332 073

• Original German name: DRUCKSCHEIBE / Pressure Disc

• Supersedes former part number: 1315 332 054

• Cross Reference OE: Eurotec 95006226, Euroricambi 95534458

• Product Type: Auxiliary Box Planetary Sun Gear Pressure Disc / Sun Gear Thrust Plate

• Brand: ZF OEM Matching Heavy-Duty Replacement Spare Parts

• Compatible Gearbox: ZF 16S151NMV, 16S1930, 16S2230, 16S2231, 16S2530, 16S2531 Ecosplit4 16-speed manual heavy truck transmission

• Applicable Vehicles: Sinotruk Sitrak/Howo, FAW J6P/J7, MAN TGS/TGX, DAF CF/XF, Iveco Stralis heavy haul tractors

• Material: High-strength alloy structural steel, surface quenching + flatness precision grinding

• Net Weight: approx 0.92kg (reference value)

• Matching Components: Sun gear, planetary pinion 1316 332 031, planet carrier, thrust washers

• Function: Axial positioning and limiting for auxiliary box sun gear, bear axial meshing thrust, maintain stable gear meshing clearance

• Category: Heavy Truck ZF 16S Series 16-Speed Transmission Auxiliary Box Planetary Reduction System Repair Spare Parts

Material & Advantages

1. High-quality alloy steel blank with surface quenching treatment, high surface hardness, resistant to impact abrasion and indentation under continuous axial thrust

2. Double-sided ultra-precision flat grinding, excellent flatness, uniform contact stress to prevent local concentrated wear

3. Strict OEM outer diameter, inner bore and thickness dimension, direct assembly without grinding modification during gearbox overhaul

4. Optimized surface oil storage texture, continuously form lubricating oil film to reduce friction heat between pressure disc and sun gear end face

5. Stable limiting effect eliminates sun gear axial play, effectively lower abnormal vibration and grinding noise of planetary gear set

6. Adapt to long-distance full-load highway logistics, mountain heavy climbing and frequent low-range heavy transport working conditions

Application Scenarios

• Replace worn, indented, deformed original sun gear pressure disc marked 1315 332 073 for ZF 16-speed Ecosplit4 gearbox

• Fix transmission faults including auxiliary box continuous grinding noise, sun gear axial clearance oversize, accelerated planetary gear wear

• Complete auxiliary box planetary reduction assembly disassembly overhaul and regular maintenance for fleets equipped with ZF 16-speed manual gearbox

• Assemble matched sun gear, planetary pinions and planet carrier following official ZF auxiliary box assembly standards; recommended to inspect all thrust washers simultaneously during overhaul

Supply & After-sale

• MOQ: 1 piece

• Warranty: 3–6 months (exclude contaminated transmission oil, overload heavy hauling, improper assembly and natural abrasion aging)

• Packaging: Independent shockproof foam + thick carton sealed packaging to protect flat working surface from scratch and extrusion deformation

• Remarks: Confirm gearbox model ZF 16S Ecosplit4 series before order placement; this part replaces old version 1315 332 054, fully interchangeable
