VG750/270
ZF
VG750/270
Max Input Torque: 11,000 Nm
Max Input Rotation Speed: 3,500 rpm
High Speed (On-road) Ratio: 1.00
Low Speed (Off-road) Ratio: 2.00
Max PTO Output Torque (Optional NA200): 2,000 Nm
Max Continuous Operating Temperature: 130℃
Oil Capacity: 6.4L (without differential) / 5.5L (with differential)
High-pressure gravity cast aluminum integrated housing, lightweight 115kg base body without differential, high rigidity, anti-vibration and corrosion resistance, greatly reduce vehicle dead weightZF Friedri...;
Unique three-shaft design, no reverse rotation of output shaft, effectively protect front/rear axle drive system and extend axle service life;
Pneumatic two-speed shifting system, fast high-low gear switching response, support in-gear shifting at low speed;
Lockable planetary differential lock, fully locked front & rear axle power output to maximize traction on slippery, muddy and steep slopes;
Noise-optimized precision ground alloy steel gears, stable meshing, low running noise under full-load off-road operation;
Integrated built-in lubrication oil pump, support external oil cooler connection, stable circulation lubrication under high temperature continuous work;
Complete ADM automatic drive train management compatible, electronic control differential lock automatic engagement, reduce driver operation burden;
Standard multi-position mounting flange, universal installation for 4x4 / 6x6 all-wheel-drive vehicles, no cutting or frame modification during assembly;
Multi-layer high-temperature fluorine rubber sealing system with ventilation breather, adapt wading construction operation, effectively prevent gear oil leakage;
Strict torsion impact, continuous high-load fatigue and high-low temperature aging test before delivery, stable performance for long-term mine, fire fighting and crane operation.
Special trucks: Fire fighting trucks, military off-road trucks, oilfield service trucks, sanitation all-wheel-drive vehicles, road rescue vehicles
Construction machinery: Mobile truck cranes, off-road mining dumpers, wheeled engineering vehicles, mountain concrete mixers
Compatible with MAN, DAF, IVECO, Sinotruk Sitrak, Shaanxi Delong all-wheel-drive heavy tractors equipped with ZF 16S / 12TX series transmissions.
