Basic Info
Alias: Splitter Shift Control Valve / Gearbox Air Shift Valve Assy / ZF16S Sub Gear Control Valve
Product Name: ZF16S1650 Gearbox Pneumatic Shift Valve Body OEM 4630630050
Brand: ZF
Applicable Vehicles: MAN TGX, IVECO Trakker, DAF XF/CF heavy tractors equipped with ZF16S1650 16-speed manual transmission
Category: Heavy Truck ZF Ecosplit Transmission Parts – Pneumatic Splitter Shift Valve Assembly
Weight Parameter
Net Weight: 2.1KG
Gross Weight: 2.6KG with export carton packing
Material & Feature
Integrated high-density cast iron valve body, stable dimensional accuracy, anti-deformation under long-term compressed air impact;
Internal precision ground valve spool, low air leakage rate, sensitive response for frequent high-low gear switching;
Standard air inlet, air outlet and exhaust thread ports fully comply with ZF original factory pipeline layout, no pipe modification during installation;
Built-in dustproof air filter structure inside air passage, block road dust from entering valve core to avoid jamming;
Wear-resistant rubber sealing rings on all valve spool matching surfaces, anti-aging and resistant to high-temperature gearbox oil vapor corrosion;
Optimized internal air flow channel design to reduce air resistance and shorten half-gear shifting response time;
Strict air tightness test, reciprocating shift fatigue test and temperature cycle test before delivery, stable control performance under -30℃~130℃ working temperature range.
Application
Perfectly matched European heavy-duty logistics tractors, bulk cargo haulage trucks, mining transport vehicles and refrigerated semi-trailers fitted with ZF16S1650 Ecosplit 16-speed gearbox; widely used in cross-border highway trunk transportation, mountain full-load freight and complex muddy construction road operation scenarios..
Origin & Lead Time
Shiyan warehouse maintains continuous spot stock, deliver goods within 1–2 working days after payment; bulk wholesale orders take 3–6 working days, sea shipping cycle ranges from 8 to 22 days.
MOQ & Packing
MOQ: 1 piece
Warranty: 4–6 months, warranty void for man-made pipeline damage, improper installation and long-term lack of brake fluid maintenance
Packing: Anti-rust protective film + shockproof bubble wrap + thick neutral export carton, moisture-proof and anti-collision for long ocean transportation
